Wifi Electronic Door Lock With Tuya APP Remotely / Biometric Fingerprint / Smart Card / Password / Key Unlock
Both Support Tuya / Smartlife APP
Fingerprint / Password / Smart Card / Key Unlock
Temporary Password
Timed Password
Support Normal Open Mode (access free)
Diffrence Mortise Lock Size
English Voice
Frosted Shell
Universal Both for Right or Left Door
For 35-100mm Door Thickness
Specifications:
Brand: RAYKUBE
Model: R-FG5 Plus
Support Wifi connecting: Tuya Version
Material: Aluminium Alloy
Unlock mode: APP / Fingerprint / Password / Smart card / Key
Fingerprint read: FPC Sensor (Semiconductor Sensor)
Color: Gold / Black
Card User: 100
Fingerprint User: 100
Chip Type: Dual Core Driver
Read time: 0.3seconds
Touch screen: IML Material
Working power: 4 x AAA 1.5V batteries (not include)
Operating temperature: -25 to 55 Centigrade
Password function: support virtual password
Suit for the door thickness about 35 -100mm
Battery box in the back handle, use 4pcs AAA 1.5V battery. (battery not include)
![]()
Inside Locked Switch:
If turn on this switch, commond user can not open lock by Fingerprint / Password / Card from outside. Unless the Admind User can open lock from outside.
![]()
Tuya APP Function:
1.Connect to the wifi direct, not need any gateway;
2.Unlock remotely by phone APP;
3.Get the unlock record when someone open the lock;
4.Make the temporary password / timed password in APP
APP Screen shot details:
![]()
![]()
About Installtion:
This lock suit for the door thickness 35-100mm door thickness.
please measure your old mortise lock size, and check our all options different mortise lock size which one suit for your door. That will more easy replacement.
We have 24+ different size mortise lock size for choose
if you don’t know how to choose the size, please contact us.
Item Include:
Front panel x 1
Rear panel x 1
Mortise lock x 1(options)
Smart card x 5
Mechanical Key x 2
Screw Kit x 1
![]()
Item Specifics
Item Specifics
Brand Name:
RAYKUBE
Origin:
CN(Origin)
Certification:
NONE
Material:
aluminium alloy
Model Number:
R-FG5 Plus
Direction 1:
Right Push
Direction 2:
Right Pull
Direction 3:
Left Push
Direction 4:
Left Pull
Battery Size:
AAA 1.5V (4pcs)
Wifi:
2.4G
Material:
Aluminium Alloy
